ZTEX USB-FPGA-Module 1.2: Spartan 3 FPGA Board with EZ-USB Microcontroller
Product Category:
Development Boards & Kits
Vendor:
ZTEX GmbH
Product Supported / Obsolete?:
supported The ZTEX USB-FPGA-Module is intended for prototyping or small series development. In combination with an extensible Experimental Board it can be used as a development or evaluation board.
The ZTEX USB-FPGA-Module bases on a Xilinx Spartan-3 XC3S400 FPGA and a high speed Cypress CY7C68013A/14A EZ-USB-Microcontroller.
Rapid development can be achieved using the Open Source Firmware Kit.
Product Description:
Features
- High-Speed (480 MBit/s) USB interface via Mini-USB connector (B-type)
- Cypress CY7C68013A/14A EZ-USB-Microcontroller
- Xilinx Spartan-3 XC3S400 FPGA
- 60 General Purpose I/O's (GPIO):
- 52 FPGA GPIO's
- 8 EZ-USB FX2 GPIO's (4 if Flash option is installed)
- 20 special I/O's (SIO):
- 6 SIO's for FPGA configuration including JTAG
- 2 serial ports (4 pins)
- I2C interface (2 pins)
- 2 interrupts
- 3 timers
- 1 clock output
- 1 Wakeup pin
- 1 Breakpoint pin
- Flash memory (optionally)
- 128 Kbit EEPROM memory
- Open Source SDK
- FPGA configuration / programming via USB (No JTAG adapters or other additional utilities required.)Access to EEPROM and Flash memory
- Access to EEPROM and Flash memory
- FPGA configuration / programming from Flash memory
- Many examples
Block diagram
Product image
