SMT398-8000-4-Z4-Q2

SMT398 is a BIG ‘Big-Brother’ to the SMT358 FPGA Modules that Sundance designed in 1999 and has all the same benefits – and a lot more!
The latest versions of the Xilinx Virtex-II are being used to the fullest of their potentials and offers the benefit of QDR and ZBT-RAM with no less than four Sundance High-speed Busses (SHB) for general purpose I/O and interface to high-speed DAQ/DSP Modules, six interModule ComPorts and an enhanced 32-bit Global Bus interface to a Carrier.

The specification for the cooling fan used on some versions of our Modules can be found here. The manufactures Web-site.

Features

Single width module

Virtex IItm range of FPGA devices as user programmable resource

8M Gates equivalent or more of software configurable resource. XC2V8000-4 FF1152 package

4 Banks of 512Kb x 18 of high speed ZBT SRAM, 4 Mbytes

2 Banks of 512Kb x 18 of high speed QDR-SRAM, 2 Mbytes

6 ComPorts or SDL Interface (Sundance Datapipe Links @ 100Mbytes/sec.), 72 I/O pins

32-bit Global Connector for Host-PC transfers, 78 I/O pins

Four SHB Interfaces (Sundance High-speed Bus @ 400Mbytes/sec.), 240 I/O pins

4 Status LEDs

External Clock

LVDS Interface and memory expansion options

JTAG Diagnostics Port

TIM standard compatible.

12 months warranty
