NI PCI-7811R

[+] Enlarge Picture 160 digital lines configurable as inputs, outputs, counters, or custom logic at rates up to 40 MHz
User-defined triggering, timing, and onboard decision making with 25 ns resolution
1M gate reconfigurable I/O (RIO) FPGA for parallel processing power
Connectivity to the NI cRIO-9151 for analog and digital I/O expansion/signal conditioning
High-speed digital pattern generation with 80 KB of onboard memory and DMA data streaming
Built-in examples for I2C, SPI, S/PDIF, RS232 and other digital communication protocols
Data Sheet | Configure System

Overview Specifications Pricing Services Resources Step 1: Verify Device and Quantity Selection
Part
Number Description Est Ship Days US Dollars
(change) Qty
779363-01 NI PCI-7811R -- For price, select country
Each NI PCI-7811R requires: 1 Cable, 1 Connector Block

NI PCI-7811R Cable Connector Block

Step 2: Select Cable
Part
Number Description Est Ship Days US Dollars
(change) Qty
Shielded
191667-01 SHC68-68-RDIO Cable (1m)
NI Recommended -- For price, select country
186381-01 SH68-C68-S Cable (1m) -- For price, select country
186381-02 SH68-C68-S Cable (2m) -- For price, select country
186381-0R5 SH68-C68-S Cable (0.5m) -- For price, select country
189152-01 NSC68-5050 Cable Assembly (1m) -- For price, select country
189041-02 SHC68-NT-S Cable Assembly (2m) -- For price, select country
Step 3: Select Connector Block
Part
Number Description Est Ship Days US Dollars
(change) Qty
Screw Terminals
776844-01 SCB-68 - Shielded
NI Recommended -- For price, select country
Step 4: Select Optional Accessories
Part
Number Description Est Ship Days US Dollars
(change) Qty
Software
778694V-09 LabVIEW FPGA Module + 1 Yr SSP -- For price, select country
Step 5: Add to Cart or Get a Quote

Please select the country where you will use the product(s) so that we can provide you with accurate pricing, availability, and purchasing information

The National Instruments PCI-7811R features user-defined, onboard processing for complete flexibility of system timing and triggering. Instead of a fixed ASIC for controlling device functionality, R Series intelligent DAQ uses an FPGA-based system timing controller to make all 160 digital I/O lines configurable for application-specific operation. The FPGA chip is configured by creating LabVIEW block diagrams with the LabVIEW FPGA Module. Your block diagram executes in the hardware, giving you direct, immediate control over all I/O signals to deliver high-performance capabilities such as:

- Complete control over the synchronization and timing of all signals and operations
- Custom onboard decision making that executes with hardware-timed speed and reliability
- Digital lines individually configurable as inputs, outputs, counter/timers, PWM, flexible encoder inputs, or specialized communication protocols

With intelligent DAQ and LabVIEW FPGA, you can configure user-defined hardware for a wide variety of applications, such as custom digital data acquisition, high-speed waveform generation, sensor simulation, hardware-in-the-loop (HIL) test, digital protocol emulation, bit error rate testing, and other applications that require precise timing and control.

Recommended Accessories
The SHC-68-68-RDIO cable is designed and shielded specifically for the DIO connectors on R Series devices for improved signal integrity when connected to terminal blocks or the cRIO-9151 R Series expansion chassis.

Low-Cost, High-Performance Signal Conditioning for R Series Intelligent DAQ
The NI cRIO-9151 R Series expansion chassis connects directly to any digital connector on R Series devices and houses up to four C Series I/O modules for low-cost signal conditioning, analog I/O expansion and direct connectivity. For more information on I/O availability, please reference the related links below.

Data Sheet | View Pricing and Purchasing Information »

Additional Product Information
Manuals (2)
Data Sheet

Related Information
NI LabVIEW FPGA
3-min Introduction to Intelligent DAQ
NI cRIO-9151 R Series Expansion Chassis
Advanced Data Acquisition Techniques with Intelligent DAQ
What can I do with LabVIEW FPGA?
LabVIEW FPGA On-line Tutorial
R Series Frequently Asked Questions
FPGA-Based Control Frequently Asked Questions
Intelligent DAQ – Web Event On Demand
View Pricing and Purchasing Information »

Specifications Documents
Data Sheet

Specifications Summary
General
Bus Type PCI
OS Support Windows, Real-Time, RTX
Product Family R Series
Real-Time Compatible Deterministic single-point control, Robust critical test
Triggering Digital
Analog Input
Number of Channels 0
Analog Output
Number of Channels 0
Digital I/O
Number of Channels 160 DIO
Timing Static, Hardware timed (< 10 MHz), Hardware timed (>= 10 MHz)
Logic Levels TTL
Maximum Input Range 0..5 V
Maximum Output Range 0..5 V
Input Current Flow Sinking, Sourcing
Programmable Input Filters Yes
Output Current Flow Sinking, Sourcing
Current Drive (Channel/Total) 5 mA/0.8 A
Watchdog Timer Yes
Programmable Power-Up States Yes
Handshaking I/O Yes
Pattern I/O Yes
Counter/Timers
Number of Counter/Timers 160
Resolution 64 bits
Maximum Source Frequency 80 MHz
Minimum Input Pulse Width 12.5 ns
Logic Levels TTL
Maximum Range 0..5 V
Timebase Stability 100 ppm
GPS Synchronization No
Pulse Generation Yes
Buffered Operations Yes
Debouncing/Glitch Removal No
Number of DMA Channels 3
Physical Specifications
Length 17 cm
Width 11 cm
I/O Connector 68-pin VHDCI female

View Pricing and Purchasing Information »
