FIR Filter using DPRAM
"The eInfochips generic FIR filter core provides optimal results for a higher number of taps. It has 80 I/O pins and the user can change the coefficients at run time. Only a single Signed Multiplier unit is used. It accepts 16-bit signed sampled inputs and 16-bit signed coefficients. 32-bit signed outputs of the multiplier is supplied to an adder which is working on pipeline concept. The final output of an adder can achieve up to 32-bit precision.
Device Family Support
Virtex-II
Virtex-E
Virtex
Spartan-IIE
Spartan
Key Features
Up to 1024 taps
16-bit input and coefficient data precision
32-bit output data
Uses dual-port RAM for sample and coefficient data storage"
