Digital Audio Serial Input, Configurable

May 29, 2007 - 9:47am — fc
IP Vendor:
Coreworks
IP Target Vendor:
Xilinx
IP Type:
Design
IP Category:
Audio, Video and Image Processing
IP Supported FPGA Device:
Spartan-3
Spartan-3E
Spartan-IIE
Virtex
Virtex-4 FX
Virtex-4 LX
Virtex-4 SX
Virtex-5 LX
Virtex-5 LXT
Virtex-5 SXT
Virtex-II Pro
IP Description:

"CWda16 IP core is a configurable stereo audio interface component designed to input a serial digital audio stream. The CWda16 supports the well known I2S interface format originally developed by Philips and also the Left-Justified or Right-Justified serial audio formats. The CWda16 can be configured at runtime to support two (16, 20, 24 or 32 bit) audio channels read from two different addresses in an interleaved manner, or two 16-bit audio channels read in parallel from the same register.

Device Family Support
# Virtex-5 LXT
# Virtex-5 LX
# Virtex-5 SXT
# Virtex-4 FX
# Virtex-4 LX
# Virtex-4 SX
# Virtex-II Pro
# Spartan-3E
# Spartan-3
# Spartan-IIE

Key Features
# Configurable input format: I2S, Left Justified or Right justified (chosen at runtime)
# Configurable sample FIFO depth (at pre-synthesis time)
# Supports user configurable sample width (at runtime)
# Supports up to 32 bits per sample
# Supports all commonly used sample rates including 32, 44.1, 48, 96, 192 and 384 kHz
# Runtime Configurable read method.
# Flexible CW-Link interface, which permits bridging to standard interfaces (I2S, IBM CoreConnectTM, AMBATM AHB, etc)"
