Accelerated Display Graphics Engine (BADGE)

IP Vendor:
BitSim AB
IP Target Vendor:
Xilinx
IP Type:
Design
IP Category:
Audio, Video and Image Processing
IP Supported FPGA Device:
Spartan-3
Virtex-4 FX
Virtex-4 LX
Virtex-4 SX
Virtex-II Pro
IP Description:

"BADGE provides graphics acceleration for drawing common graphical shapes, such as lines, rectangles, text and copying rectangles (BitBLT) between different locations on screen. BADGE includes a number of GPUs (Graphics Processing Units). These work in parallel for generating the accelerated graphics in the graphics memory. The different GPUs have different functionality. Only the needed GPUs will be implemented, thus getting an efficient use of the FPGA resources.

Device Family Support
# Virtex-4 FX
# Virtex-4 LX
# Virtex-4 SX
# Virtex-II Pro
# Spartan-3L
# Spartan-3

Key Features
# Provides HW-accelerated graphics for embedded systems
# Modular design that ensures flexibility
# Adaptable for a wide range of processors
# Handles graphics, text and analog and digital video
# Advanced features: alpha blending and anti-aliasing
# Supports both OS users (drivers) and non-OS users (API)
# Fully synchronous and technology independent RTL code"
