I/O Designer
I/O Designer provides bi-directional integration, data management and the ability to perform concurrent design of your FPGA and PCB. Focused on optimizing system performance, designer productivity and reducing product manufacturing costs, I/O Designer eliminates the barriers between FPGA and PCB flows and design organizations.
Benefits
* Reduces PCB Manufacturing costs by eliminating PCB signal layers
* Makes achieving high-speed constraints possible
* Reduces the total product design cycle time by changing a serial process into a concurrent process
* Eliminates PCB re-spins due to bad FPGA symbols on the PCB
* Eliminates the costs associated with creating and maintaining the FPGA symbol(s) for the PCB schematic
