FPGA's - Arty Artix-7

September 30, 2015 - 6:38pm

What timing! my first post on FPGA’s & Xilinx/Digilent/Avnet announce a Arduino compatible entry level FPGA!

Digilent now also have it @ $99 & avail from 15th Oct. It’s the same board as Avnet’s, as the logos of both Digilent & Avnet are on the board.

XiLinx, have now updated their product page for the Arty, with documentation & a short video on their blog.

Xilinx says the kit includes –

  • Full seat Vivado® Design Suite: Design Edition
    • Node locked & Device-locked to the Artix-7 XC7A35T FPGA, with 1 year of updates and support

The catch is that after one year of  free updates, updates may be a bit pricey, not the cost of the initial purchase ($3k!), but expect a few $$’s. Of course if the S/W is stable, there may be no need to upgrade for a few years or so, if at all.

I’m not sure how many FPFA’s have Arduino headers but one from HackaDay, may have been a predecessor, as it was mentioned in XiLinx’s blog.

Papilio also have an open-source hardware and software project, FPGA board with Arduino headers, that can use a customised Arduino IDE. And then “It lets you draw up circuits without investing time and energy in learning VHDL/Verilog”.

And then there is the Mojo V3, it doesn’t seem to have directly compatable Arduino headers but does use an Arduino IDE to include Arduino libraries in their projects.

Of course FPGA’s have the ability to “Software Define” any processor, if it can fit into the FPGA. Presumable the Arty already has the avrmega 8-bit series mcu defined with plenty of support.

Digilent have good VHDL or Verilog tutorials extracted from one of their textbooks, that now would be a good time to work through & just see if I can really make sense of these gizzmo’s! And if so then maybe place an order for the Arty!

Categories: Planet FPGA


September 29, 2015 - 5:27am

Well, it’s almost inevitable to cross path’s with FPGA’s (Field Programmable Gate Arrays) when playing around with micro-controllers, embedded systems & digital electronics. To me they’ve been a black box and  a bit of a mystery, even though they have been around for a while.

After reading FPGA’s For Dummies, followed by the DE0 Nano User Manual, they started to make a bit more sense. Throw in a VHDL Tutorial  and this FPGA intro,  and I’m getting the general idea.

The FPGA devices are dominated by XiLinx & Altera, who provide Hardware Development Environments with a choice of HDL’s (Hardware Design Languages) – VHLD or Verilog. Companies like Digilent also offer a range of development boards.

FPGA’s main advantage are their parallel computing capabilities, and for that reason they are worth knowing about even for hobbyists. However the development boards are more expensive compared to mcro-controllers & SBC’s like BeagleBone’s etc.  And they are considerably more complex &  offer a whole new range of challenges.

There are many applications that use FPGA devices, even the Analog Discovery uses a XiLinx FPGA. They can be used in Bitcoin mining, Big Data applications & Video processing. High End development boards cost $10k+, whereas entry level dev boards start from approx $100.

An understanding of Digital Logic is essential & the more the better. I’ve brushed up a bit with Basic Digital Electronics to give well a basic understanding of Digital Electronics, it certainly helps but I think I need to do more to be able to tackle FPGA’s. I’m getting there & hope to try one out shortly, as they offer a whole new field of exploration or maybe more realistically a world of “bleeding-edge” pain!

With no specific project in mind, except maybe setting up a Led Matrix array, I’m not sure what I would do with one, other than to work through various tutorials & projects I can find on the net. I’ll keep an eye out for any projects that may be of use & post it here of course!

Interesting … I just noticed that Digilent is now offering (as yet unavailable! & price unknown) a new dev board Arty Artix-7 with Arduino headers. It seems comparable to the Basys3, minus a few of the buttons, leds & 7 segment displays & also most importantly – no $10 Vivado Design Edition (big loss!). Instead it’s supplied with the free Web Edition development environment, which may be enough.

Nevertheless it should be a good entry level FPGA, especially after working thru the Make:AVR Programming book. I expect it too be a bit cheaper than the Basys3, but maybe not by much. It should provide a lot more interest as a stepping stone to using a FPGA. Although I don’t think this is the first FPGA dev board to include Arduino headers.

Well there you go… hot of the press…Avnet Introduces New “ARTY” Xilinx Artix-7 35T FPGA Evaluation Kit   & Product Brief from Avnet, interestingly it includes a Xilinx Vivado: Design Edition, device locked licence. And at a price @ $99 v $149 for the Basys3.

Categories: Planet FPGA

Mystery FPGA Circuit Feels the Pressure

September 27, 2015 - 10:01am

You have an FPGA circuit and you want the user to interact with your circuit by pushing a button. Clearly, you need a button, right? Not so fast! [Clifford Wolf] recently found a mysterious effect that lets him detect when someone pushes on his iCEstick board.

The video below shows the mystery circuit (which is just the stock iCEstick board), which appears to react any time you flex the PC board. The Verilog implements a simple ring oscillator (basically an inverter with its output tied to its input).

Here’s an excerpt from his Verilog code:

// ring oscillator wire [99:0] buffers_in, buffers_out; assign buffers_in = {buffers_out[98:0], chain_in}; assign chain_out = buffers_out[99]; assign chain_in = resetn ? !chain_out : 0; SB_LUT4 #( .LUT_INIT(16'd2) ) buffers [99:0] ( .O(buffers_out), .I0(buffers_in), .I1(1'b0), .I2(1'b0), .I3(1'b0) );

He compares the output frequency to a known frequency from the onboard crystal oscillator and registers large shifts as a push. At first we thought it might be mechanical flex on the crystal, but if you watch the video, the output of the ring oscillator is clearly shifting on a touch. Presumably (and this is a guess), small changes in the capacitance and other circuit parameters have an effect on the ring oscillator’s frequency. [Clifford] says he has many theories, but doesn’t know which one (if any) is correct.

We can’t decide if we’d depend on this effect or not in practice. But it does seem repeatable in the video. Maybe [Clifford] has invented a new product category: the Field Programmable Gate Array and Switch (FPGAS). We’ve mentioned [Clifford’s] work before on project iCEstorm and even used his open source tool chain in our FPGA tutorial (look for another one soon, by the way).

Thanks for the tip [James Bowman].

Categories: Planet FPGA

FPGA Controlled Reflow Oven

September 25, 2015 - 10:06am
"This FPGA Project was completed on Christmas Day 2013. I wanted to assemble surface mount components, and to do this I need a reflow oven. Everybody on the internet seems to build their own, so I set about building one using a FPGA. Everything has been implemented inside the FPGA, without there being any software in the control loop."
Categories: Planet FPGA

DisplayPort with an FPGA

September 23, 2015 - 1:01pm

One of the challenges with display technology is the huge increase in bandwidth that has occurred since LCD panels took over from Cathode Ray Tubes. Low end laptops have a million pixels, UHD (“4K”) displays
have 8 million and the latest Full Ultra HD (“8k”) displays have over 33 million pixels. Updating all those pixels takes a lot of bandwidth – to update a 4k display at 60 Hz refresh rates takes close to a gigabyte per second. 8 billion bits – that is a lot of bits! That’s why VGA ports and even DVI ports are starting to vanish in favor of standards like HDMI and DisplayPort.

The current release of HDMI is 2.0, and is tightly licensed with NDAs and licensing fees. VESA, who created the DisplayPort standard, states the standard is royalty-free to implement, but since January 2010, all new DisplayPort related standards issued by VESA are no longer available to non-members.

So after receiving a new Digilent Nexys Video FPGA development board, Hackaday regular [Hamster] purchased a UHD monitor, scoured the internet for an old DisplayPort 1.1 standard, and started hacking.

A couple of months and 10,000 lines of VHDL code later what may be the first working Open Source DisplayPort
implementation is available. The design includes a 16-bit scrambler, an 8b/10b encoder, and multichannel support.

We had noticed that [Eli Billauer] had done something similar, but as far as we know his source is unreleased (although he has some interesting notes about what he found). Although [Hamster] is the first to admit that it is not yet production ready, this forms a base for the others who will no doubt follow. Nothing makes life easier than a reference implementation to compare against!

The video below is a talk about DisplayPort 1.3 from [CraigWiley] who is on the VESA standards committee and includes a good overview of the technical details at a high level. If you are looking for other Displayport hacks, you can drive an external display from an iPad or even drive a Retina display from any Displayport output.

[DisplayPort Plug Image by Belkin CC-BY-SA]

Categories: Planet FPGA

Altera MAX10 DECA Board Fun Projects - Part 1 Graphics

September 21, 2015 - 9:22pm

DECA, a new Altera MAX10 FPGA evaluation board from Arrow/Terasic, is the most versatile low cost FPGA board I have.
I’m planning to write a series covering some projects for DECA, and the graphics is the first topic.
I’m using Quartus 15.0 for Linux Update 2 for the projects.

Here’s some details about the DECA.
Currently it sells for $169. Arrow holds a series of global workshops covering DECA since May 2015.
The small form factor FPGA board packs with features:

  • High end MAX10 device with 50,000 LEs, and pin count 22×22
  • 4 PLLs
  • Dual ADCs
  • 512MB DDR3
  • 64MB Flash
  • 10/100 Ethernet
  • USB2.0 OTG
  • SDHC
  • HDMI v1.4 Transmitter
  • MIPI CSI-2
  • 24bit Audio
  • 2 SMA inputs
      Various sensors
    • Gesture, Proximity/Ambient light
    • Humidity and temperature
    • Power monitor
    • Accelerometer
  • BeagleBone I/O expansion headers

The board I have is an evaluation kit comes with a wireless WiFi/BLE BeagleBone Cape and a 8M camera module. In my opinion, BeagleBone I/O expansion makes many kinds of interesting DIY projects possible.

The graphics for MAX10 is implemented in VIP (Altera Video and Image Processing Suite IPs).
The following block diagram shows the FPGA setup and software processes for graphics rendering.
DECA VIP Graphics
There are some challenges, the tough hardware and software ones are listed below:

  • Choosing proper parameters for VIP components to generate proper video timing signals
  • Low graphics rendering frame rate. In 1024×768 resolution, HMI application’s rendering performance is in the range of couple frames per second.
Hardware Challenges

To address the video timing issue (i.e., pixels drawn to the screen are not properly displayed), different parameters are tried to configure IP cores. This design uses DDR3 controller with 64 bit Avalon interface data width. The Frame Reader IP (VFR), which converts user graphics/image/video data stored in external memory to a video stream understood by VIP, should have the same master port data width as the DDR3 controller. According to the VIP user guide, VFR’s control register “Frame Words” should be “The number of words (reads from the master port) to read from memory for the frame”.
VFR Registers
To calculate the “Frame Words”, VFR pixel counts is used as the dividend and 2 (64/32) as the divisor. This configuration worked for one resolution, but not in other resolutions. Different VFR’s master port widths were tried (32 and 128), but had the same result. After days of struggles, I finally settled down the proper parameter combination working with all 640×480, 800×480 and 1024×768 resolutions.

IP Parameter Value DDR3 Controller Avalon Interface Data Width 64 Frame Reader Master Port Width 256 Color Plane Sequencer Halve Control Packet Width disabled

Other key things I learned from hardware perspective:

  • With the current configuration, it can only have up to two VFRs in the design, or Quartus Analysis & Synthesis, namely quarts_map, will crash. I believe the reason is the hardware resource limitation from the parts used in DECA
  • To get correct DDR3 pin assignments and interconnects, run deca_vip_mem_if_ddr3_emif_p0_pin_assignments.tcl at least once, after Analysis & Synthesis but before Fitter (Place & Route) compilation. The reminding notice is buried in synthesis compiling messages.
Software Challenges

The graphics software demonstration is done in uCOS II environment, it has 3 tasks. The main task performs HMI (Human-Machine Interface) displaying 640×480 automotive glass cluster.

HMI GlassCluster

The other rendering task draws two vertical and horizontal bars in 800×480 screen. The third task moves the main HMI screen.
When the HMI screen is in 1024×768 resolution, the rendering frame rate is in the range of 1 to 2 fps. If the resolution is reduced to 640×480, fps improves but is still slow. Further investigation indicates the performance issue lies within HMI code itself, not necessary due to VIP or graphics implementation.
HMI code used is based on Altia’s proprietary framework.
In theory, the graphics hardware has enough bandwidth to drive a 640×480 32bit/pixel screen approaching 30 fps.
The following NIOS II Eclipse screenshot shows assembly and C code snippet of a pixel filling routine.
Pixel Filling
The Nios II Gen 2 softcore is clocked by a 100MHz PLL. Assuming in a best scenario, there is no CPU pipeline stall, no RTOS context switch, and one clock cycle per instruction.
The inner loop (j loop) takes:
2 + ( 2 + ( 5 + 6 ) * inner_loop_count ) cycles.
The outer loop (i loop) takes:
( 2 + ( inner_loop_cycles + 7 + 6 ) * outer_loop_count ) cycles
Therefore to update 640×480 pixels screen, cycle total needed is 3,388,320, or it takes about 33ms or in 30 fps. This is a simplified case, the actual frame rate depends on rendering content and will be of course much lower.
VFR supports two frame buffers, and the feature is very useful for double buffering. While displaying the front buffer, you can build scene in the back buffer and swap the buffers when the back buffer building is done. Although it won’t improve rendering performance, the technique effectively eliminates video flickering. The demo code for the drawing task uses the approach.

The hardware design, software demo code and HMI library, plus prebuilt FPGA bitstream and application binary are available at:
Note: I don’t have commercial VIP license, the prebuilt bitstream is time-limited.
You may need turn off and then on the HDMI monitor for the monitor to pick up the video signal (at least for the Sceptre monitor I’m using).

This video clip shows the complete process to configure FPGA, download and run graphics demo from command line, and debug the code from Eclipse for Nios.

Categories: Planet FPGA


September 21, 2015 - 4:01am

When you think of a CNC controller you probably think of a PC with a parallel port or some microcontroller-based solution like a Smoothie Board. [Mhouse1] has a different idea: use FPGAs as CNC controllers.

FPGAs inherently handle things in parallel, so processing G code, computing curves and accelerations, and driving multiple stepper motors at one time would not be an issue at all for an FPGA. Most computer-based designs will have slight delays when trying to drive everything at once and this introduces some mechanical jitter. Even worse jitter occurs when you have an old PC trying to run everything when some other task takes over the CPU.

In all fairness, [Mhouse1’s] design does  include an Altera CPU on the FPGA to handle some tasks that CPUs are good at, but the FPGA allows the design to create I/O devices specifically for the task at hand. The CPU is also running an RTOS (MicroC OS II) and a Python GUI that runs on a controlling PC.

There’s an older article about using an FPGA to control a CNC machine that has a lot of good information about designing such a beast, if you are interested. However, that design is a lot less ambitious than this one. [Mhouse1] wants the controller to be machine agnostic, and he’s demonstrated it on a cheap DVD-based laser cutter as well as a modified Shapeoko machine.

If you want an introduction to FPGAs, you might want to get started with our tutorial on cheap FPGA development. Or, you can learn a lot with just your Web browser.

Categories: Planet FPGA

j1 - almost

September 16, 2015 - 6:10am

A while back I had a poke at porting the J1 FORTH softcore to Altera.

Yep, ahead of my meanderings with the Altera LABS but I have spent years in software development and real-time DSP and other systems so the LABS are just me being methodical and giving back to the community.  My main aim, eventually, is DSP and vision experiments.

Not being a slouch I then speed off to at least play at a larger level of granularity and so the FORTH softcores.

Any old how, J1 did allude me because it is coded for XILINX and had some pesky RAM code definition that did not come with the J1.  Ended up finding the XILINX code for the RAM and so I have got most of the way through the porting.  Just some pesky problems with Altera version of Verilog not covering the same expanse of the spec as the XILINX compiler.

All good, as it is all a learning vehicle.

Stay tuned then.

Categories: Planet FPGA
